Switch between guide bushing and non-guide bushing type (standard) and machine bar stock up to ∅ 25 mm (option)

• Shorter production cycles with no loss of precision and versatility

• Live tools at any turret location, and 3 gang locations

• Indexing by high speed servo

• Y axis gang tool motion

Extra Axes for Precision and Versatility

• 13 programmable axes

• A axis for robotic arm, workpiece pick-off, in-process gaging, automatic tool measurement and more

• Front and back work performed simultaneously

Designed for Maximum Convenience

• Low turret position and 45° slant improves accessibility

• PC-based CNC controller

Machine Specifications

LFV Technology

We provide next-generation machining tools to greatly reduce or eliminate a host of chip-related problems during cutting, taking your productivity to the next level.

LFV technology stands for low frequency vibration cutting. The servo axes are vibrated in the axial direction using a unique control technology where by cutting is performed while synchronizing this vibration with the rotation of the spindle. This cutting method introduces regular "air-cutting" into the cycle, breaking up of chips into very small pieces making it the optimum processing method for difficult-to-machine materials.
